FOUR POSITION CASING
Discharge can be located in any of four positions. Casing is close
grain iron of 30,000 psi minimum tensile strength. Back pull-out design
eliminates the need to disturb piping should the pump ever require
service - the casing stays in the line.
REPLACEABLE CASING WEAR RING
Prevents wear on casing and is easy to replace.
EASY TO SERVICE
Taking out only 4 cap screws allows removal of pumping assembly
without disturbing piping.
ENCLOSED BRONZE IMPELLER
Enclosed bronze impeller is of latest hydraulic design for maximum
efficiency. It is balanced for vibration free operation and threaded onto
stainless steel motor shaft.
MECHANICAL SHAFT SEAL
Standard self-adjusting shaft seal for temperatures to 225°F (107°C)
and pressures to 150 psi (1034kpa). Ceramic seat and carbon seal
face for long trouble-free service. Special seals are available for higher
temperatures and fluids other than water.
Standard pump motors have open drip proof construction and are rated
with jet pump service factors for continuous duty operation. Motors are
56 frame size with NEMA standard mounting flange, one piece threaded
stainless steel shaft and ball/ball bearing construction.
After careful assembly and inspection, EVERY pump is factory tested
and will meet Hydraulic Institute standards
